CLM6-B25/1 Minyatür Devre Kesici - 6kA - B eğrisi

Şalt Ürünler / Eaton / Otomatik sigorta (MCB)

CLM6-B25/1 Minyatür Devre Kesici - 6kA - B eğrisi - 1x25A

Ürün Kodu : EP-504657

..: Stokta Mevcut :..

5,03 €

Favorilerime Ekle

Ürün Açıklaması

EP-504657 - CLM6-B25/1 Minyatür Devre Kesici - 6kA - B eğrisi - 1x25A


Barkod	:	EP-504657
Oem	:	EP-504657
MPN	:	EP-504657

SKU	194723 Model Kodu: HL-B25/1
descriptionLabel	Eaton Moeller series xPole - HL/HL-HX MCB. HL, xPole Home, 1-pole, tripping characteristic: B, rated current In: 25 A, rated switching capacity IEC/EN 60898-1: 4,5 kA
General specifications
	Product Name	Eaton Moeller series xPole - HL/HL-HX MCB
	Catalog Number	194723
	EAN	9010238062078
	Product Length/Depth	85 mm
	Product Height	73 mm
	Product Width	17.7 mm
	Product Weight	0.12 kg
	Compliances	RoHS conform
	Model Code	HL-B25/1
Delivery program
	Application	Switchgear for residential and commercial applicationsxPole Home - Switchgear for residential applications
	Number of poles	Single-pole
	Number of poles (total)	1
	Number of poles (protected)	1
	Tripping characteristic	B
	Release characteristic	B
	Amperage Rating	25 A
	Type	HLMiniature circuit breaker
Technical Data - Electrical
	Voltage type	AC
	Rated operational voltage (Ue) - max	230 V
	Rated insulation voltage (Ui)	440 V
	Rated impulse withstand voltage (Uimp)	4 kV
	Frequency rating - min	50 Hz
	Frequency rating - max	60 Hz
	Rated switching capacity (IEC/EN 60898-1)	4.5 kA
	Overvoltage category	III
	Pollution degree	3
Technical Data - Mechanical
	Width in number of modular spacings	1
	Built-in depth	44 mm
	Degree of protection	IP20
	Connectable conductor cross section (solid-core) - min	1 mm²
	Connectable conductor cross section (solid-core) - max	25 mm²
	Connectable conductor cross section (multi-wired) - min	1 mm²
	Connectable conductor cross section (multi-wired) - max	25 mm²
Design verification as per IEC/EN 61439 - technical data
	Rated operational current for specified heat dissipation (In)	25 A
	Heat dissipation per pole, current-dependent	0 W
	Equipment heat dissipation, current-dependent	3 W
	Static heat dissipation, non-current-dependent	0 W
	Heat dissipation capacity	0 W
	Ambient operating temperature - min	-25 °C
	Ambient operating temperature - max	75 °C
Design verification as per IEC/EN 61439
	10.2.2 Corrosion resistance	Meets the product standard's requirements.
	10.2.3.1 Verification of thermal stability of enclosures	Meets the product standard's requirements.
	10.2.3.2 Verification of resistance of insulating materials to normal heat	Meets the product standard's requirements.
	10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects	Meets the product standard's requirements.
	10.2.4 Resistance to ultra-violet (UV) radiation	Meets the product standard's requirements.
	10.2.5 Lifting	Does not apply, since the entire switchgear needs to be evaluated.
	10.2.6 Mechanical impact	Does not apply, since the entire switchgear needs to be evaluated.
	10.2.7 Inscriptions	Meets the product standard's requirements.
	10.3 Degree of protection of assemblies	Does not apply, since the entire switchgear needs to be evaluated.
	10.4 Clearances and creepage distances	Meets the product standard's requirements.
	10.5 Protection against electric shock	Does not apply, since the entire switchgear needs to be evaluated.
	10.6 Incorporation of switching devices and components	Does not apply, since the entire switchgear needs to be evaluated.
	10.7 Internal electrical circuits and connections	Is the panel builder's responsibility.
	10.8 Connections for external conductors	Is the panel builder's responsibility.
	10.9.2 Power-frequency electric strength	Is the panel builder's responsibility.
	10.9.3 Impulse withstand voltage	Is the panel builder's responsibility.
	10.9.4 Testing of enclosures made of insulating material	Is the panel builder's responsibility.
	10.10 Temperature rise	The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
	10.11 Short-circuit rating	Is the panel builder's responsibility. The specifications for the switchgear must be observed.
	10.12 Electromagnetic compatibility	Is the panel builder's responsibility. The specifications for the switchgear must be observed.
	10.13 Mechanical function	The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
Additional information
	Current limiting class	3
	Features	Additional equipment possible
	Special features	Ambient temperature hint: a 1 °C increase results in a 0.5% linear reduction of current carrying capacity
	Suitable for	Flush-mounted installation
	Used with	HL Miniature circuit breaker
