BZMD1-A32 Kompakt Şalter (Sabit termik-manyetik korumalı) 3x32A 15kA

Şalt Ürünler / Eaton / Kompakt Devre Kesiciler (MCCB)

BZMD1-A32 Kompakt Şalter (Sabit termik-manyetik korumalı) 3x32A 15kA

Ürün Kodu : Y7-109715

..: Stokta Mevcut :..

99,80 €

Favorilerime Ekle

Ürün Açıklaması

Y7-109715 - BZMD1-A32 Kompakt Şalter (Sabit termik-manyetik korumalı) 3x32A 15kA


Barkod	:	Y7-109715
Oem	:	Y7-109715
MPN	:	109715

SKU	109715 Model Kodu: BZMD1-A32
descriptionLabel	Eaton Moeller series Circuit breaker BZMD1, Three-pole, 32 A, 415 V, Screw connection
General specifications
	Product Name	Eaton Moeller series BZM - Molded case circuit breaker
	Catalog Number	109715
	EAN	4015081093014
	Product Length/Depth	130.2 mm
	Product Height	86 mm
	Product Width	75 mm
	Product Weight	0.83 kg
	Compliances	RoHS conform
	Model Code	BZMD1-A32
Delivery program
	Type	Circuit breaker
	Number of poles	Three-pole
	Amperage Rating	32 A
	Features	Protection unit
Technical Data - Electrical
	Voltage rating	415 V - 415 V
	Amperage Rating	32 A
	Instantaneous current setting (Ii) - min	320 A
	Instantaneous current setting (Ii) - max	480 A
	Overload current setting (Ir) - min	0 A
	Overload current setting (Ir) - max	0 A
	Short delay current setting (Isd) - min	0 A
	Short delay current setting (Isd) - max	0 A
	Rated short-circuit breaking capacity Ics (IEC/EN 60947) at 400/415 V, 50/60 Hz	15 kA
	Electrical connection type of main circuit	Screw connection
	Handle type	Rocker lever
	Overvoltage category	III
	Pollution degree	3
Technical Data - Mechanical
	Mounting Method	DIN rail (top hat rail) mounting optional Built-in device fixed built-in technique
	Mounting Method	DIN rail (top hat rail) mounting optional Built-in device fixed built-in technique
	Degree of protection	IP20
	Number of auxiliary contacts (change-over contacts)	0
	Number of auxiliary contacts (normally closed contacts)	0
	Number of auxiliary contacts (normally open contacts)	0
	Position of connection for main current circuit	Front side
Design verification as per IEC/EN 61439 - technical data
	Rated operational current for specified heat dissipation (In)	32 A
	Equipment heat dissipation, current-dependent	7.7 W
Design verification as per IEC/EN 61439
	10.2.2 Corrosion resistance	Meets the product standard's requirements.
	10.2.3.1 Verification of thermal stability of enclosures	Meets the product standard's requirements.
	10.2.3.2 Verification of resistance of insulating materials to normal heat	Meets the product standard's requirements.
	10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects	Meets the product standard's requirements.
	10.2.4 Resistance to ultra-violet (UV) radiation	Meets the product standard's requirements.
	10.2.5 Lifting	Does not apply, since the entire switchgear needs to be evaluated.
	10.2.6 Mechanical impact	Does not apply, since the entire switchgear needs to be evaluated.
	10.2.7 Inscriptions	Meets the product standard's requirements.
	10.3 Degree of protection of assemblies	Does not apply, since the entire switchgear needs to be evaluated.
	10.4 Clearances and creepage distances	Meets the product standard's requirements.
	10.5 Protection against electric shock	Does not apply, since the entire switchgear needs to be evaluated.
	10.6 Incorporation of switching devices and components	Does not apply, since the entire switchgear needs to be evaluated.
	10.7 Internal electrical circuits and connections	Is the panel builder's responsibility.
	10.8 Connections for external conductors	Is the panel builder's responsibility.
	10.9.2 Power-frequency electric strength	Is the panel builder's responsibility.
	10.9.3 Impulse withstand voltage	Is the panel builder's responsibility.
	10.9.4 Testing of enclosures made of insulating material	Is the panel builder's responsibility.
	10.10 Temperature rise	The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
	10.11 Short-circuit rating	Is the panel builder's responsibility. The specifications for the switchgear must be observed.
	10.12 Electromagnetic compatibility	Is the panel builder's responsibility. The specifications for the switchgear must be observed.
	10.13 Mechanical function	The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
